DMT 螺旋型/止付螺絲固定式/撓性聯軸器
尺寸
| 型號 | D | I | L | G | M | d1xd2 標準孔徑 公差(H8) | Mass 質量 (g) | |
| Min | Max | |||||||
| DMT-16 | 16 | 4 | 23 | 2.5 | M3 | 4 | 8 | 10 |
| DMT-16S | 16 | 4 | 16 | 2.5 | M3 | 4 | 8 | 8 |
| DMT-19 | 19 | 6.5 | 23 | 3 | M3 | 6 | 8 | 13 |
| DMT-19S | 19 | 4.5 | 19 | 3 | M3 | 6 | 8 | 11 |
| DMT-20 | 20 | 8 | 26 | 3 | M4 | 6 | 10 | 13 |
| DMT-25 | 25 | 10 | 31 | 4 | M4 | 6 | 12 | 31 |
| DMT-25S | 25 | 7 | 25 | 4 | M4 | 6 | 12 | 29 |
性能
| 型號 | 一般扭力 (N.m) | 最大扭力 (N.m) | 最高回轉數 (min) | 容許偏心 (mm) | 容許偏角 (o) | 容許軸向位差 (mm) |
| DMT-16 | 0.5 | 1.0 | 25000 | 0.25 | 5 | ±0.25 |
| DMT-16S | 0.5 | 1.0 | 25000 | 0.25 | 5 | ±0.25 |
| DMT-19 | 1.0 | 2.0 | 25000 | 0.25 | 5 | ±0.25 |
| DMT-19S | 1.0 | 2.0 | 25000 | 0.25 | 5 | ±0.25 |
| DMT-20 | 1.1 | 2.2 | 25000 | 0.25 | 5 | ±0.25 |
| DMT-25 | 1.6 | 3.2 | 25000 | 0.25 | 5 | ±0.25 |
| DMT-25S | 1.6 | 3.2 | 25000 | 0.25 | 5 | ±0.25 |
