水稻收割機鏈條 3318

產品型號： 3318.5-A0680106

描述

鏈號 Chain No.	節距 Pitch	滾子直徑 Roller diameter	内節内寬 Width between inner plates	銷軸直徑 Pin diameter	銷軸長度 Pin length		齒形角 Tooth angle	鏈板尺寸 Plate dimension			鏈板厚度 Plate thickness	極限拉伸載荷 Ultimate tensile strength	平均拉伸載荷 Average tensile strength
	P	d1 max	b1 min	d2 max	L max	Lc max	a	h1	h2	H	t/T max	Q min	Qo
	mm	mm	mm	mm	mm	mm	a	mm	mm	mm	mm	KN	KN
3318.5-A0680106	33	10.1	18.5	7	29	31	70°	10	13	38	1.6	19.6	22.5
3325-4LB1.35	33	10.1	25	7	37	39.5	90°	10	13	38	2	19.6	24
3325-41B1.45	33	10.1	25	7	35.6	37.6	70°	10	13	38	1.7	19.6	22.5
3325-3572	33	10.1	25	7	36.8	39	70°	10	13	38	2.0/1.6	19.6	23
3325-1E6410	33	10.1	25	7	36.8	39	90°	10	13	38	2.0/1.6	19.6	23
3325-3555	33	10.1	25	7	36.8	39	70°	10	13	38	2.0/1.6	19.6	22.5
3330-4LB1.15	33	10.1	30	7	40.3	42.7	60°	10	13	43	1.7	19.6	22.5
3330-4LB1.45-01	33	10.1	30	7	40.3	42.7	70°	10	13	38	1.7	19.6	22.5
3340-3572	33	10.1	40	7	51.8	54	70°	10	13	38	2.0/1.6	19.6	23
3340-1E8570	33	10.1	40	7	49.2	52.5	90°	18	10	38	1.6/1.2	19.6	22
3350-3555	33	10.1	50	7	60.2	62.5	70°	18	10	43	1.6	19.6	22.5
3325-49200	33	12.8	25	7	35.9	38.7	70°	10	13	38	1.6	21.6	24.5
3358-1E8350	33	10.1	58	7	68	72	90°	18	10	38	1.6	19.6	22.5
3358-1E7070	33	10.1	58	7	68	72	90°	18	10	38	1.6	19.6	22.5
3358-6365	33	10.1	58	7	68	72	70°	18	10	43	1.6	19.6	22.5
354MJ875	35	10.1	40	7	50.2	52.5	70°	18	10	43	1.6	19.6	22.5
3540-3572	35	10.1	40	7	50.2	52.5	70°	10	10	35	1.6	19.6	22.5
3558-4LB1.35	35	13.2	58	9.4	70	73.2	90°	15	18	47	2.03	22.54	27
3550-5080	35	10.1	50	7	60.2	62.5	70°	18	10	38	1.6	19.6	22.5
